Tuttnauer LabSci 15L: 65L automatic laboratory benchtop autoclave for liquids, glassware, plastics and instruments. Plug & play (no plumbing), 230V single-phase. Sold and supported by Alpha Scientific Repair Services Ltd in BC, Alberta and Saskatchewan. Call for a Quote: 1-888-818-4847.
The Tuttnauer LabSci 15L is a 65-liter automatic laboratory benchtop steam autoclave for sterilizing liquids, media, unwrapped instruments, plastics and glassware. It has an advanced multi-color control panel, an electropolished 316L/316Ti stainless-steel chamber, a built-in printer and four validated cycles (glass, plastic, liquid A, liquid B-waste), plus up to 16 custom cycles. Plug & play: no plumbing is needed, and it runs on standard 230V single-phase power. A stainless steel stand is included free with the autoclave.
Not the LabSci 15+L: the 15L shares the same 15" chamber diameter and front footprint as the 15+L, but its chamber is shorter (65 L vs 85 L) and the unit is 30.1" deep instead of 37". It also uses single-phase NEMA 6-20 power, while the 15+L needs three-phase NEMA L15-20. That makes the 15L the simpler choice for labs that don't have three-phase service. Compare the LabSci 15+L.
Alpha Scientific Repair Services Ltd is an authorized Tuttnauer dealer. We sell and support the LabSci 15L across BC, Alberta and Saskatchewan with factory-trained technicians, set-up guidance and ongoing service. Call for a Quote: 1-888-818-4847 (or 604-690-3389).
| Chamber volume | 65 L |
|---|---|
| Chamber dimensions (dia. x D) | 15" x 19.7" (brochure); product page lists 15" x 20" |
| Max available loading height | 12.1" |
| External dimensions (W x H x D) | 28.3" x 21.3" x 30.1" |
| Electrical | 230V, 1 phase, 60 Hz, NEMA 6-20 |
| Utilities | No plumbing required |
| Cycles | 4 validated (glass, plastic, liquid A, liquid B-waste); up to 16 custom |
| Temperature probes | 2 integrated probes for liquids |
| Documentation | Built-in printer; stores up to 200 past cycles viewable on a PC |
| Chamber material | 316L or 316Ti stainless steel, electropolished |
| Stainless steel stand | Free with autoclave |
| Trays | Included |
| Optional features (all tabletop LabSci) | Warming (95-104 deg C), Isothermal (80-94 deg C), F0, 21CFR with R.PC.R software |
| Manufacturer warranty | 2 years parts |
| Flask | 250 ml | 500 ml | 1000 ml | 2000 ml | 3000 / 5000 ml |
|---|---|---|---|---|---|
| Erlenmeyer | 17 | 11 | 6 | 3 | 0 |
| Schott-Duran | 27 | 16 | 11 | 6 | 0 |
Specifications are from Tuttnauer's official LabSci 15L product page and LabSci brochure. Please confirm electrical and installation requirements for your facility before ordering.
No. The LabSci 15L has a 65 L chamber (15" dia. x 19.7" D) and runs on 230V single-phase power (NEMA 6-20). The LabSci 15+L has a larger 85 L chamber (15" dia. x 27.2" D), is deeper overall (37" vs 30.1") and needs 230V three-phase power (NEMA L15-20).
Yes. It includes liquid A and liquid B-waste cycles, and Tuttnauer specifies two integrated temperature probes for liquid loads.
No. Tuttnauer states no water utility connections are needed: plug in and add water. It requires a 230V, 60 Hz single-phase circuit with a NEMA 6-20 receptacle.
Per the Tuttnauer LabSci brochure: up to 17 x 250 ml, 11 x 500 ml, 6 x 1000 ml or 3 x 2000 ml Erlenmeyer flasks; or 27 x 250 ml, 16 x 500 ml, 11 x 1000 ml or 6 x 2000 ml Schott-Duran flasks.
A built-in printer documents date and time, temperature, pressure and system messages. The unit stores up to 200 past cycles that you can open on a PC, which supports inspection readiness.
Alpha Scientific Repair Services Ltd, an authorized Tuttnauer dealer, sells and services LabSci autoclaves in BC, Alberta and Saskatchewan. Call 1-888-818-4847 (or 604-690-3389).
For pricing, availability and installation guidance in BC, Alberta and Saskatchewan, call 1-888-818-4847 (secondary 604-690-3389).
